Soil pH tester
Model:FT-TP1
Brand:fengtu
Related products
Product details
1.Soil pH tester product introduction
Soil pH tester consists of a host and a sensor that can be inserted directly into the soil to detect soil pH, including a PH parameter sensor.The Soil pH tester is a highly integrated multi-functional environmental monitoring device with an integrated structure design that can quickly and accurately measure the pH value in the soil.This instrument is not only suitable for instant detection of soil parameters at multiple locations and at different depths, but also supports long-term continuous monitoring, providing users with detailed soil data analysis.
It is widely used in agriculture, forestry, geological exploration, plant cultivation, water conservancy, environmental protection and other industries.It provides scientific basis and technical support for soil moisture detection, dry farming water-saving irrigation, precision agriculture and other fields, helping users better understand and optimize soil conditions and promote sustainable development practices.
2.Soil pH tester function introduction
1.Compact and beautiful: compact design, easy to carry to field operations, suitable for long-term outdoor use.
Simple and easy-to-use operation interface: Users can get started without complicated training.After the host is connected to the sensor, records can be stored manually, or the sampling interval can be set arbitrarily through the host to automatically store the recorded data to ensure an efficient workflow.
2.Large-screen color LCD display: real-time tracking and recording of the pH value, group number and low-voltage status of each measured environmental factor, making the information clear at a glance.
Built-in large-capacity memory: supports data storage of up to 10 million items, and has a power-off data protection function to ensure data security and integrity.
3.Automatically identify sensors: After inserting sensors with different parameters, the host can automatically identify them, ensuring consistency between sensors without affecting measurement accuracy.
Flexible combination of sensors: Users can combine sensors according to their needs, and sensor interfaces with different parameters can be used interchangeably to adapt to various measurement needs.
4.Multi-channel automatic detection expansion: supports simultaneous access and synchronous detection of multiple sensors, which improves work efficiency and is especially suitable for situations where multiple locations or depths need to be measured.
5.Convenient data export: The recorded data can be exported to the computer through the USB interface at any time.It supports EXCEL format output and generates data curves to facilitate further data analysis and processing.
Over-limit warning function: Provides the function of setting the coloring of over-limit areas, and provides color-changing warnings for data that exceeds the preset range.It serves as an important reference for environmental assessment and helps users quickly identify abnormal situations.
6.Wireless uploading to the cloud platform: The optional 4G networking function can wirelessly upload the historical data stored in the machine to the smart cloud agricultural platform to achieve remote data management and long-term trend analysis, which greatly facilitates the user experience.
Data management platform: Users can access the cloud platform through the network, view and manage data anytime and anywhere, and improve data utilization efficiency.
3.Soil pH tester technical parameters
Charging input voltage | 4.5V-5.5V |
Charging current | <2A |
screen size | 3.5 inches |
screen resolution | 480*800☆ |
screen interface | MIPI DSI☆ |
USB interface | 2 (Supports external expansion of mouse, keyboard, 4G, etc.)☆ |
Type-C | 1 (Supports external expansion of mouse, keyboard, 4G, etc.)☆ |
RS485 | 2 (Supports Modbus, json, asc input, etc.) |
External sensor supply voltage | 12V |
External sensor supply current | 1A |
operating system | ftiot (based on Linux-5.4)☆ |
CPU | 2*Cotex-A7, 650Mhz☆ |
RAM | 512M DDR3☆ |
Flash | 8G-64 |
OpenGL | ES 2.0☆ |
Wifi | support |
4G | Optional |
button | support |
capacitive touch screen | support |
software architecture | B/S☆ |
web access | Support☆ |
MTP mode | Support☆ |
Multiple terminal login | Support☆ |
IPV6 | Support☆ |
Sensor communication method | RS485, TCP, UDP, HTTP☆ |
Data forwarding method | RS485, TCP, UDP, HTTP☆ |
Remote SSH | Support☆ |
remote debugging | Support☆ |
Soil pH | Measuring range: 0~14.00 (PH) Accuracy: ±0.1PH, ±0.1℃ Resolution: 0.01 |
