Corn southern rust monitor

Corn southern rust monitor

Model:FT-YM6

Brand:fengtu

Corn southern rust monitor is generally installed in the corn field and can monitor the meteorological environment parameters of the corn planting area online.

Product details

1.Corn southern rust monitor product description

Corn southern rust monitor is generally installed in the corn field and can monitor the meteorological environment parameters of the corn planting area online.Corn southern rust monitor collects information about the growth environment of corn planting areas and predicts the incidence of corn diseases based on the system's built-in model.At the same time, the built-in spore capture device collects spore inventory and its diffusion dynamics, providing an unmanned, visual verification method for the occurrence of corn diseases.The device is mainly composed of a spore capture device, a spore carrier, an image acquisition device, a network transmission module, a power supply, and a lightning protection system.It can realize functions such as remote automatic capture of disease spore information, automatic rotation of the glass slide, automatic acquisition, automatic microscopic imaging photography, automatic uploading of image data, and automatic operation.It provides services for modern agriculture, meets the needs of disease prediction and specimen collection, and prevents and controls the occurrence of diseases in a timely manner.

2.Corn southern rust monitor performance characteristics

1.Stainless steel spray-coated shell, 15-inch ultra-large high-definition capacitive touch screen, windows operating system, with good human-computer interaction interface.

2.It has a 12-megapixel, 1,000-fold magnification microscopic imaging system that can automatically take high-definition microscopic photos of captured pathogen spores.The clarity of the captured images can meet the requirements for manual identification of pathogen spore types.

3.The equipment automatically captures pathogen spores 24 hours a day, automatically takes pictures of the captured pathogen spores, and automatically selects the best pictures to upload.

4.The fully intelligent automatic microscopic imaging system can automatically adjust the camera's shooting angle to achieve all-round, no-dead-angle imaging of the slide.

5.It can realize the whole process of automatic operation from glass slide loading, pathogen spore capture, microscopic imaging to glass slide recovery.

6.Equipped with extra-long special glass carrier tape, which can meet the usage of 600 days.

7.It has multiple working modes, and the automatic operation mode, timing operation mode and debugging operation mode can be switched freely.

8.Built-in Beidou/GPS positioning function, which can upload device information to the platform in real time, and view current device parameters on the map.

9.The equipment's feeding, collection, microscopic imaging, recycling and other actions can be controlled through the platform and APP.

10.Remote upgrade and maintenance: The latest program can be directly and automatically updated remotely without the need for manual on-site replacement.

11.Multiple data access methods: You can access the platform through PC, view data through mobile APP, and control device actions.

12.4G communication module is standard, and 5G communication module is optional.

13.With fault self-diagnosis mechanism, equipment fault information can be reported to the remote server in real time.After-sales personnel can view equipment fault information through the platform.

14.It can be equipped with an intelligent solar power supply management system to collect key information such as equipment power consumption, solar power generation, battery voltage, equipment load, current, etc.and upload it to the server (optional).

15.It has a traffic alarm function.The device can be bound to its traffic card through the platform, and alarm information will be automatically pushed when the traffic is abnormal.

3.Corn Southern Rust Monitor Technical Parameters

1.Material: GB32080-92 stainless steel

2.Data transmission method: 4G/5G network (optional), wired network

3.Power supply voltage: AC 220V ± 5%

4.Power: 200W

5.Timing: 5 time periods can be set

6.Carrier tape: Length: 150M Width: 0.025M Can meet 600 days of use

7.Air collection outlet wind speed: 0.3~5 m/s

8.Insulation resistance: ≥2.5MΩ
