Tailings Monitoring

Tailings Monitoring

Model:FT-WK1

Brand:fengtu

Tailings Monitoring is an important technical parameter to judge the wetting line, reservoir level monitoring, deformation monitoring, precipitation monitoring and so on.

Product details

1.Tailings Monitoring Background

Tailings Monitoring is an important technical parameter to judge the wetting line, reservoir level monitoring, deformation monitoring, precipitation monitoring and so on.Tailings ponds are an important part of non-coal mine safety production and one of the major sources of danger in this field. Once an accident occurs, it will cause huge losses to the lives and property safety of people downstream, cause serious pollution to the local environment, and have a serious negative impact on local economic development and social stability. Therefore, the State Administration of Work Safety issued the "Notice on Doing a Good Job in the Installation of Online Monitoring Systems for Tailings Ponds" in 2013, requiring that all third-class and above tailings ponds establish online monitoring systems by the end of 2013. Fourth-class tailings ponds are encouraged to install online monitoring systems.

2. Tailings Monitoring System Overview

Our tailings pond online monitoring system uses sensor technology, signal transmission technology, network technology and software technology to monitor key technical indicators that affect the safety of tailings ponds and dams from a comprehensive perspective of macro and micro, record historical and existing data, and analyze future trends in order to assist enterprises and governments in making decisions, improve the safety level of tailings ponds, and effectively prevent and curb major accidents. The system relies on an intelligent software system to establish an analysis and early warning model, and integrates it with the SMS platform. When an abnormality occurs, it automatically sends a short message to the mine management personnel in a timely manner to start the corresponding plan as soon as possible.

3. Main monitoring contents of Tailings Monitoring

1. Reservoir water level monitoring module

2. Dam body infiltration line monitoring

3. Dam displacement monitoring: including surface displacement, internal displacement, horizontal displacement, and settlement monitoring

4. Rainfall monitoring

5. Dry beach monitoring: including beach top elevation, dry beach length, dry beach slope, etc.

6. Leakage monitoring

7. Video monitoring

4. Tailings Monitoring Project List

Monitoring itemsDevice NameMonitoring itemsDevice Name
Surface displacement monitoringGNSS ReceiverDry beach monitoringHigh frequency radar level meter
Internal displacement monitoringTandem fixed inclinometerReservoir water level monitoringPore water pressure gauge
Wetting line monitoringPore water pressure gaugeRainfall monitoringDigital high-precision rain gauge
Video surveillanceHD Network Box Camera

5. Tailings Monitoring Basis

"Safety Technical Regulations for Tailings Dams AQ2030-2010"

"Technical Specifications for Tailings Pond Online Safety Monitoring System Engineering GB 51108-2015"

6. Tailings Monitoring Implementation Function

1. Comprehensive, all-weather real-time monitoring and real-time surveillance capabilities: Automated monitoring of each monitoring point of the tailings pond is achieved to grasp the overall safety status of the tailings pond in real time.

2. Capability of graded early warning for tailings ponds: Once an emergency abnormal situation occurs, the system can promptly send out alarm information via SMS or software screen to achieve comprehensive early warning function.

3. Realize basic data management and historical data storage: realize monitoring data storage, intuitively display the historical changes and current status of various monitoring and surveillance data information, and provide simple, clear, intuitive and effective reference information for the safe production management of mining enterprises.

4. Realize data interconnection with relevant departments to meet the authority management function: It has authority management, authority login, and authority negotiation functions to realize different management and data sharing of reservoir area safety monitoring information within the company and the competent department, and can realize sharing at the city, county, and mine levels.
