Leaf Wetness Sensor
Model:FT-YSW
Brand:fengtu
Related products
Product details
1.Leaf Wetness Sensor Product Overview
Leaf Wetness Sensor is used to measure the humidity of the leaf, which can accurately measure the whole range of the leaf and directly indicate the water requirement state of the plant.The Leaf Wetness Sensor consists of a high-precision thermistor and a transmitter, which can accurately measure the temperature in the entire range. The humidity sensor is based on the principle of dielectric constant measurement, simulates the shape of the leaf, and truly simulates the surface characteristics of the leaf. The humidity can be accurately measured by the change of the dielectric constant on the leaf surface. With good sensitivity, it can detect trace amounts of residual moisture on the leaf surface. The leaf temperature and humidity transmitter adopts a waterproof design, low power consumption, and can be continuously monitored for a long time. It is easy to install and can be hung inside the greenhouse or on the branches of trees for long-term uninterrupted monitoring. It is widely used in greenhouses, laboratories, breeding, production environments, artificial climate chambers, etc. to measure the surface humidity of plants or objects.
2. Leaf Wetness Sensor Features
1. Imitate leaf surface characteristics to quickly and accurately measure temperature and humidity.
2. Denser vein patterns (15 veins/cm) can detect smaller droplets and make measurements more sensitive.
3. The humidity measurement is sensitive and can accurately detect the surface humidity of the leaves.
4. High precision, fast response and good interchangeability.
5. Epoxy resin encapsulation, waterproof and moisture-proof, longer service life.
3. Leaf Wetness Sensor Technical Parameters
DC power supply (default) | DC 5-30V | |
Maximum power consumption | 0.75W (12V DC power supply) | |
Operating temperature | -40℃~+60℃ | |
Humidity parameters | Range | 0-100%RH |
Resolution | 0.1%RH | |
Accuracy | ±3% (@0-50%, 25℃) | |
Temperature parameters | Range | -40~80℃ |
Resolution | Resolution: 0.1℃ | |
Accuracy | ±0.5℃(@25℃) | |
Protection level | IP67 | |
Sealing material | Black flame retardant epoxy resin | |
Default cable length | 2 meters, cable length can be customized as required | |
Dimensions | 65*15*138.5mm | |
Output signal | RS485 (Modbus protocol) |
